Polcd ILI8961 2.7 Tft Lcd 960X240 TFT LCD Display RGB 8 Bit 6 0'CLOCK

Brand Name : Polcd

Model Number : P027-40-V2

Certification : RoHS, ISO9001

Place of Origin : Shenzhen, China

MOQ : 1 piece

Price : Please contact us for latest price

Payment Terms : T/T, L/C, Credit card, PayPal

Supply Ability : 500,000 piece per week

Delivery Time : 5-8 working days

Packaging Details : 20 cm * 30 cm * 40 cm

Product Name : TFT Display

Size : 2.7 inch 960*240

Resolution : 960*240

Brightness (cd/m²) : 280

Interface : RGB 8bit

Driver Ic : ILI8191

Contact Now

Description:

2.7 inch TFT LCDs (Thin-Film Transistor Liquid Crystal Displays) are commonly used in various electronic devices that require a small-size display with good image quality.

It offer a reliable and versatile display solution for various applications, providing high-quality display performance, low power consumption, and customization options to meet specific application requirements.

Parameter:

Model P027-40-V2
Screen Size 2.7 inch
Number of Pixel 960RGB(H)x240(V)
Display area 40.50(H)x54.00(V)mm
Pixel pitch 0.05625(H)x0.16875(V)mm
Pins 40 pins
Outline Dimension 46.20x63.10x2.38mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally White
Viewing Direction(eye) 6 0'CLOCK
Display Color 262K
Luminance(cd/m2) 230 nit
Contrast Ratio 600:1
Interface RGB 8bit
Back-light LED Side-light type
Drive IC ILI8961
Operation Temperature -30~80℃
Storage Temperature -30~80℃

Polcd ILI8961 2.7 Tft Lcd 960X240 TFT LCD Display RGB 8 Bit 6 0'CLOCK
