Polcd 3.5 Inch TFT LCD Screen 320x480 RGB Transmissive IPS Viewing Angle

Shenzhen P&O Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Polcd 3.5 Inch TFT LCD Screen 320x480 RGB Transmissive IPS Viewing Angle

  • 1
  • 2
  • 3

Brand Name : Polcd

Model Number : P035M075-IPS

Certification : RoHS, ISO9001

Place of Origin : Shenzhen, China

MOQ : 1 piece

Price : Please contact us for latest price

Payment Terms : T/T, L/C, Credit card, PayPal

Supply Ability : 500,000 piece per week

Delivery Time : 5-8 working days

Packaging Details : 20 cm * 30 cm * 40 cm

Number of Pixel : 320RGB(H)x480(V)

Screen Size : 3.5 inch

Display area : 48.96(H)x73.44(V)

Brightness (cd/m²) : 400

Interface : 4Line SPI

Driver Ic : ILI9488

Contact Now

Item Specification Unit
Screen Size 3.5 inch

Diagonal

Number of Pixel 320RGB(H)x480(V) Pixels
Display area 48.96(H)x73.44(V) mm
Pixel pitch 0.153(H)x0.153(V) mm
Outline Dimension 54.48x84.71x2.20 mm
Pixel arrangement RGB Vertical Stripe --
Display mode Normally White --
Viewing Direction(eye) 12 0'CLOCK --
Gray inversion direction --
Display Color 262K --
Luminance(cd/m2) 400 nit
Contrast Ratio 500:1 --
Surface treatment -- --
Interface 4Line SPI
Back-light LED Side-light type --
Drive IC ILI9488
Operation Temperature -20~70
Storage Temperature -30~80
Weight -- g

Polcd 3.5 Inch TFT LCD Screen 320x480 RGB Transmissive IPS Viewing Angle

Polcd 3.5 Inch TFT LCD Screen 320x480 RGB Transmissive IPS Viewing Angle
